Jolting Table Apparatus
Used to compact cement mortar prisms 40x40x160 mm in the three gang mouldcontaining cement specimens.
The apparatus, consists of a table holding the mould, seated on a rotating cam driven at 60 r.p.m.
The drop height is 15 mm.
The machine is equipped with a digital counter which provides automatic shut off at end of preset drop numbers.
Rapid mould lock and release system allows easy and quick operation.
The supporting frame of the machine has been designed to ensure precise dimensions, table flatness, correct centering of the three gang mould on the table.
The motor and gearbox assembly is enclosed in a protective housing, which promotes user safety (the moving parts are inaccessible) and long life for the gearbox.
Jolting Table Apparatus with Soundproof Safety Cabinet is also available. The cabinet is lined internally with soundproofing material to reduce sound level conforming to CE directives.
The apparatus, consists of a table holding the mould, seated on a rotating cam driven at 60 r.p.m.
The drop height is 15 mm.
The machine is equipped with a digital counter which provides automatic shut off at end of preset drop numbers.
Rapid mould lock and release system allows easy and quick operation.
The supporting frame of the machine has been designed to ensure precise dimensions, table flatness, correct centering of the three gang mould on the table.
The motor and gearbox assembly is enclosed in a protective housing, which promotes user safety (the moving parts are inaccessible) and long life for the gearbox.
Jolting Table Apparatus with Soundproof Safety Cabinet is also available. The cabinet is lined internally with soundproofing material to reduce sound level conforming to CE directives.
EN 196-1, EN ISO 679
