Motorized Hydraulic Specimen Extruder
The Motorized Hydraulic Extruder is used for quick and smooth extrusion of soil specimens from 38 mm to 160 mm tubes and also Proctor, CBR and Marshall Moulds.
The Extruder has 60 kN capacity and 70 cm ram travel.
Specimens with different sizes can be safely collected after extrusion with the help of the adjustable V shaped sample receiving table. This V table can easily be dismounted for space saving. The hydraulic piston can be stopped at any position during the extraction.
Adaptors with different sizes should be ordered separately if required.
The Motorized Hydraulic Extruder is supplied complete with Adaptors for Ø100 mm(4”) and Ø150 mm(6”) moulds.
Ø 38 mm, Ø 50 mm and Ø 70 mm Adaptors (ring and tamper) should be ordered separately.
The Extruder has 60 kN capacity and 70 cm ram travel.
Specimens with different sizes can be safely collected after extrusion with the help of the adjustable V shaped sample receiving table. This V table can easily be dismounted for space saving. The hydraulic piston can be stopped at any position during the extraction.
Adaptors with different sizes should be ordered separately if required.
The Motorized Hydraulic Extruder is supplied complete with Adaptors for Ø100 mm(4”) and Ø150 mm(6”) moulds.
Ø 38 mm, Ø 50 mm and Ø 70 mm Adaptors (ring and tamper) should be ordered separately.
EN 13286-2, 13286-47, 12697-30; AASHTO T134, T180, T193, T245; ASTM D698, D1557, D1587, D1559, D1883, BS 598-107, 1377-4, 1924-2
